insulated wall panels

Ecopanel is a complete solution for fully insulated structural walls, floors, and ceilings.



We have three standard wall panels, each with several insulation and wall-thickness options. We also create bespoke panels for Passivhaus or ultra-low energy house applications.

STANDARD PANEL CONFIGURATION

  • Exterior cavity battens to suit specified cladding

  • Exterior weather tight membrane

  • Structural lining

  • LVL framing for the thermal envelope

  • Insulation within the framing

  • Internal air tight membrane

  • Insulated 45 mm service cavity

ECOpanel Final Render_no background.png




The Ecopanel Series



Ecopanel series
Series 90
Series 90

The economical option. Configured with 90 mm insulated framing, plus the 45 mm insulated service cavity.

Performance
Terra Lana insulation theoretical R value 3.2.
Knauf Earthwool insulation theoretical R value 4.2.

Series 140
Series 140

Our most popular option. Configured with 140 mm insulated framing, plus the 45 mm insulated service cavity.

Performance
Terra Lana insulation theoretical R value 4.4.
Knauf Earthwool insulation theoretical R value 5.5.

Series 200
Series 200

The ultra efficient option. Configured with 200 mm insulated framing, plus the 45 mm insulated service cavity.

Performance
Knauf Earthwool insulation theoretical R value 6.7.

Optional to any series - expanded cork or wood fibre insulation panel added under the weathertight membrane.






Ecopanel Installation Timelapse
